Place ends into the opening hole of ten-hole fixing holders. After the ends are pressed, turn the
ten-hole fixing holders over. The current values (mA) of each end as well as the maximum current value and average value can be read out in 4 seconds. If any test failure resulted from bad connection between the contacts, the corresponding position number of the ends can be shown on the screen. The data can be transmitted to the computer via RS 232 C.

The CanNeed DER-400 is the industry standard. The new CanNeed Enamel Rater DER-400 instrument test the coverage of the enamel coating inside food and beverage cans, aerosol-cans and also different kinds of ends. It displays an index of the amount of metal exposed by incomplete enamel coverage on a clear, easily read digital LED.

The CanNeed DER-400 Digital Enamel Rater is able to detect the exposed metal position more easily compare to the former models. The reformative electronic design makes it more sensitive, reliable and accurate. The anticorrosion characteristic of the enhanced can body support is ensured its durability. The film coated buttons are more durable and with better corrosion resistance.

The CanNeed "CND-TRK-300 Oven Temperature Tracker" is a professional oven temperature curve inspection system for the coating industry, it is including the data logger, heat insulation case, software (Chinese / English) and thermocouples. "CND-TRK-300 Oven Temperature Tracker" is use to pass through the oven with the solidifying products, and record down the real temperature during the process.

The Canneed "WWP-100 Welding Seam Ball Press Tester" is used to test the welding seam quality, including the welding seam strength and continuity of 3-piece cans.
Testing Method: place the empty cans to the clamp, align the welding seam with the ball, and then tightly press the can. The cylinder pushes the ball to slide along the welding seam. Next, take the can out to check if there are any breaches.

The Canneed “ZM-10 Digital Body Blank Gauge” is made for the quality control of can body blanks. It is a precision gauge for body blank measurement/angle measurement.

The CanNeed “CMT-100 Mobility / Lubricity Tester for Cans” is for measuring the coefficient of sliding friction of can body and bottom. It can also measure the coefficient of sliding friction of blanks.

Install the corresponding clamp and place the sample on the clamp, then put the bob-weight unit on the sample. Pull the bob-weight and the indicator will display the coefficient of sliding friction.

     The CanNeed “Seam-X-On-Line X-Ray Automatic Seam Scanner” adopts non-destructive measurement method to measure the seam quality, suitable for measuring the aluminum cans, steel cans , aluminum-iron composite cans and etc. It’s applicable for online in producing department. It’s a non-destructive, cost saving, accurate measurement and automatic equipment which can be installed on the production line to improve the sampling frequency.

Advantages:
01)Non-destructive measurement, avoid wasting samples
02)Non-destructive measurement, avoid environmental pollution and save handling charges
03)High sampling frequency, reduce the isolation inferior
04)High sampling frequency, cost saving
05)Can track the chucks corresponding to the unqualified products
06)360-degree fully scan measurement
07)Can be suitable for various types of cans
08)Higher accuracy
09)Avoid manual measurement error
10)Durable
11)Accord with the worldwide safety standards

     The CanNeed “Seam-X-On-Line X-Ray Automatic Seam Scanner” adopts non-destructive measurement method to measure the seam quality, suitable for measuring the aluminum cans, steel cans , aluminum-iron composite cans and etc. It’s applicable for online in producing department. It’s a non-destructive, cost saving, accurate measurement and automatic equipment which can be installed on the production line to improve the sampling frequency.

Advantages:
01)Non-destructive measurement, avoid wasting samples
02)Non-destructive measurement, avoid environmental pollution and save handling charges
03)High sampling frequency, reduce the isolation inferior
04)High sampling frequency, cost saving
05)Can track the chucks corresponding to the unqualified products
06)360-degree fully scan measurement
07)Can be suitable for various types of cans
08)Higher accuracy
09)Avoid manual measurement error
10)Durable
11)Accord with the worldwide safety standards

The CanNeed CTG-HP Hover Probe is combined with CTG-300/CTG-310 Coating Thickness Gauge to test the lacquer film coating thickness and weight per unit area.

     The CanNeed “Seam-X-On-Line X-Ray Automatic Seam Scanner” adopts non-destructive measurement method to measure the seam quality, suitable for measuring the aluminum cans, steel cans , aluminum-iron composite cans and etc. It’s applicable for online in producing department. It’s a non-destructive, cost saving, accurate measurement and automatic equipment which can be installed on the production line to improve the sampling frequency.

Advantages:
01)Non-destructive measurement, avoid wasting samples
02)Non-destructive measurement, avoid environmental pollution and save handling charges
03)High sampling frequency, reduce the isolation inferior
04)High sampling frequency, cost saving
05)Can track the chucks corresponding to the unqualified products
06)360-degree fully scan measurement
07)Can be suitable for various types of cans
08)Higher accuracy
09)Avoid manual measurement error
10)Durable
11)Accord with the worldwide safety standards

The CanNeed “CMT-200 Mobility / Lubricity Tester for Cans” is for measuring the coefficient of sliding friction of can body and bottom. It can also measure the coefficient of sliding friction of blanks.

Install the corresponding clamp and place the sample on the clamp, then put the bob-weight unit on the sample. Pull the bob-weight and the indicator will display the coefficient of sliding friction.

The Canneed's "CTG-300 Coating Thickness Gauge", equipped with aerodynamic levitation measuring head, provides a computer enhanced method of rapidly assessing lacquer film weight of both internal and external coatings on beverage and food cans, and also tinplate.
The system provides the following benefits to the Can and End manufacturer:Reduced lacquer consumption, Greater product quality, Better operating efficiencies and Lower spoilage.

The CanNeed Seam Sight® Full Automatic Seam Monitor has adopted the advanced optical system and Golden Lens® video capture device, which interference-free of external light source and ensured the high image definition and the measurement accuracy. The Seam Sight® system is equipped with the new seam measuring software Seam Sight®.
The CanNeed Seam Sight® -A system can automatically collect the data from STG-200-D Seam Thickness Gauge and CSG-200 Countersink Gauge. The actual seam thickness and countersink can be generated reports together with other data. To optimize the measurement process.
Measurement Process
Before cutting the sample can, use STG-200-D Seam Thickness Gauge to measure the seam thickness rate; meanwhile, use CSG-200 Countersink Gauge to measure the countersink rate; then the Seam Sight -A will collect the both data automatically.
After that, the sample can should be cut with CSS-1000 Anti-noise Seam Saw or CSS-2000 Seam Saw and placed at the camera position of the monitor. Then, the seaming images will be displayed on the screen. The auto measurement will be finished within 1 second if you press the “Confirmation” button. All images and measurement data will be saved in the system data base.

The CanNeed Seam Sight ® -B system can automatically collect the data from STG-200-d Seam Thickness Gauge and CSG-d Countersink Gauge. The actual seam thickness and countersink can be generated reports together with other data. To optimize the measurement process.
