Description
Applications
Capped Sealing Integrity Standards:
Non-carbonated PET bottle beverages: 0.2 MPa (e.g., mineral water, tea beverages)
Carbonated PET bottle beverages: 1.0 MPa (e.g., cola)
Glass bottles with crown caps: 1.0 MPa (e.g., beer)
Non-carbonated glass bottles with plastic caps and aluminium screw caps: 0.2 MPa (e.g., soy sauce and baijiu)
Canned or bottled beverages: 0.2 MPa
Advantages
- Three-station testing for improved efficiency, with both puncture and cutting methods available for measurement, offering convenience and speed.
- Direct puncture head with sample fixation for easy operation, preventing measurement failures caused by improper sealing of the puncture head.
- Adoptsafety protection measures.
- Uses imported world-renowned brand control valves, connectors, and fittings, with quality comparable to any similar products worldwide.
- High sensitivity and accurate readings.
- Uses compressed air or carbon dioxide for inflation and pressurisation.
- Constructed from oxidised aluminium, explosion-proof stainless steel water cans with mesh protection, and plastic materials, ensuring durability and longevity.
Technical Parameter
Pressure gauge display range: 0-1.6 MPa
Pressure gauge resolution: 0.05 MPa
Maximum sample size: 350 × 110 mm (height × diameter) for three samples
Dimensions: L620 × W370 × H720 mm
Net weight: 25 kg
