The CanNeed AMG-300 Aerosol Measuring Gauge is a Convenient Gauge for Aerosol Cans, it can measures 6 characteristics in 1 compact Gauge. measures the following characteristics:
1) Can Height over all (E)
2) Can Height over the seams (D)
3) Can height between the seams (F)
4) Top Outside Diameter (K),
5) Top seam Outside Diameter
6) Bottom seam Outside Diameter
The CanNeed AMG-300 saves valuable time and table space. Combine five essential aerosol can gauges into one convenient measurement Gauge.
Advantages
1) Require little training and is extremely easy to use;
2) Produce measurements with extremely high repeatability and reproducibility;
3) Hands-Free design replaces individual, manual gauges and eliminates measurement variation as the result of operator interference.
Technical Parameter
|
Model |
AMG-300 |
AMG-500 |
|
Measure range |
0 – 300 mm |
0 – 500 mm |
|
Long |
590 mm |
790 mm |
|
Width |
630 mm |
630 mm |
|
Height |
400 mm |
400 mm |
|
weight |
33 kg |
39 kg |
|
Resolution |
0.005 mm |
|
|
Accuracy (20°C): |
± 0.02mm |
|
|
Power supply |
85-230 V , 50-60Hz |
|
